LINK-MI LM-TV04S 2x2 Mini Video wall controller HDMI + USB input source TV Wall Controller Splicing Box







1^st Instroduction

Model No. : LM-TV04S

Product Type: 2x2 HDMI Video Wall Controller

 LM-TV04S is a high-definition LCD TV wall controller with 4 pictures, ultra narrow edge LCD screenand projector, and support 4 way HDMI signal output, and it can connect four LCD TV or other display devices.We can according to user needs, customized 1x2 1x3 1x4 2x1 2x2, 3x1, 4x1.The product uses high definition processing chip to support the input and output of 1080P.













2^nd Application

1) Video wall function - 1 big image displaying on multiple splicing screens



2) Splitter function - Multiple same image displaying on multiple splicing screens separately







3) Mirror Function (Each display unit supports 180° rotation )

Because many LCD TVs are with wide upper border and narrow lower border, there will appear image upside down when flipping the upper screens to make the video wall. Through Mirror Function, user can individually set each display unit 180° rotation or not.

                                  Before setting                            After setting



4) Horizontal 0 and Vertical mosaic pitch 0

A complete image is strong pulled some distance due to the physical gap of the LCD, making the image deformed/distorted.

Horizontal and Vertical mosaic pitch 0 setting adjusts the size of the jointing horizontal and vertical assembly size to makes the image lost part of it, but keep image without deformation, as shown below:

                             Before setting                              After setting





5) U disk playback function

 LM-TV04S Splicing LCD processor can realize USB playing and splicing function. Users in the realization of the basic function of LCD splicing, and then realize simple video or picture format splicing playback, only need to our product USB interface insert a U disk can be achieved, without the need to configure a computer or other playback equipment, simple and practical.USB can support some commonly used videos, pictures, MP3, TXT documents. LM-TV04S Splicing LCD processor can support video playback can be selected or select, support all video round robin play / pause, fast forward, program list and other functions.









6) Support Full HD resolution up to 1080p@60Hz





7) Metal case and strong shield for better heat dissipation
